Bioinspired Extreme Materials Laboratory

11

Instron ELECTROPULS E3000 dynamic fatigue tester

Instrument overview: This equipment enable to apply dynamic loads across a temperature range of 25 °C to 350 °C, enabling evaluation of material mechanical behavior under various thermal conditions. With an additional cooling device, the environmental chamber can operate at temperatures down to -100 °C, allowing measurement of the mechanical properties of materials at low temperatures. In addition, it can apply dynamic linear loads of up to 3,000 N and measure material properties at high frequencies exceeding 100 Hz.

10

Instron 68SC-1 universal testing system

Instrument overview: This instron 6800 Series universal testing system provide exceptional performance with unparalleled accuracy and reliability. This instrument offers up to 5 kHz data acquisition and ±0.5% accuracy down to 1/1000th of load cell capacity.

9

Corona poling machine

Instrument overview: This corona poling system enables polarization of samples without direct electrode contact, using high-voltage poling tip to impart piezoelectric properties. It supports up to 30kV / 2mA, allows sample heating up to 380°C, and offers adjustable tip-to-sample distance from 0 to 100mm, providing versatile control for piezoelectric material research.

8

Optical Microscope (LEICA DM2700 M)

Instrument overview: This equipment enables high-magnification optical imaging with magnifications of up to 1000×. It allows various measurements, such as the length of samples within the image, to be performed according to the magnification.

7

OLYMPUS-BX51 INDUSTRIAL MICROSCOPE

Instrument overview: The Olympus BX51 is an upright research microscope designed for high-resolution imaging. It features a trinocular head with 10× eyepieces and a nosepiece supporting 5×, 10×, 20×, and 50×, 100× objectives, providing versatile magnification options. The microscope offers both transmitted and reflected light illumination and includes an integrated polarizer, allowing for polarized light analysis.

6

Labogene 1236R Centrifuge

Instrument overview: Labogene 1236R centrifuge utilizes high-speed rotation to generate centrifugal force, separating components based on density differences. This centrifuge can control temperature at range of -20°C to 40°C. Also, it allows rapid pre-cooling to 4°C within approximately 5 minutes before sample loading.

5

DI water system

Instrument overview: This DI water system produces both 1st-grade DI water (purified water) and 3rd-grade DI water (ultrapure water), with a flow rate of 15 L/hr. The water meets high-purity standards, including RO water conductivity of 0–25 µS/cm and UP water resistivity of 18.2 MΩ·cm, providing reliable quality for laboratory use.

4

Ohaus aquasearcher ab33ph

Instrument overview: This equipment allows for quick parameter settings, pH and conductivity calibration, and real-time data logging with up to 1000 records. This device can be connected to a computer to measure pH and temperature changes in real time. It offers continuous and automatic measurement modes. It can measure pH form -2 to 14, allowing you to measure and record pH changes in various solutions in real time.

3

Formlabs Form 4

1. Major Specifications

•Printing Technology: Low Force Display™ (LFD) based mSLA (Masked Stereolithography)

•Light Engine: LPU 4 (Light Processing Unit 4) – Features 60 high-power LED backlights

•Light Wavelength: 405 nm

•User Interface: 7-inch high-resolution touchscreen (1280 x 800)

•Connectivity: Wi-Fi (2.4/5GHz), Ethernet, USB-C

2. Printing Performance & Precision

•Max Print Speed: 100 mm/h (Most prints completed within 2 hours)

•Average Print Speed: 40 mm/h

•XY Resolution: 50 ㎛ (Achieves smoother surfaces through advanced anti-aliasing)

•Layer Thickness (Z Resolution): 25 – 300 ㎛

•Dimensional Tolerance: ± 0.15 % (Average)

3. Build Size & Physical Specs

•Max Build Volume (W x D x H): 200 x 125 x 210 mm

•Total Build Volume: 5.25 L

4. Material Compatibility

•Proprietary Resins: Supports over 38 resins from the Formlabs library (Standard, Engineering, Medical, etc.)

•Resin Handling: Next-generation automated resin cartridge system (Faster dispensing compared to previous models)

2

INTAMSYS FUNMAT HT

The FUNMAT HT is a professional FFF (Fused Filament Fabrication) 3D printer designed for high-performance engineering plastics, such as PEEK and ULTEM, which require exceptional thermal resistance.

1. Major Specifications

•Printing Technology: FFF (Fused Filament Fabrication)

•Max Nozzle Temperature: 450 °C (Equipped with a high-temperature all-metal hotend)

•Max Bed Temperature: 160 °C

•Max Chamber Temperature: 90 °C (Ensures constant internal temperature to prevent warping and shrinkage)

•User Interface: 3.5-inch or 4.3-inch color touchscreen (Varies by model version)

•Connectivity: SD Card, USB

2. Printing Performance & Precision

•Max Print Speed: 30 ~ 300 mm/s (Recommended speed varies by material)

•Layer Thickness (Z Resolution): 0.05 ~ 0.3 mm (50 ~ 300 ㎛)

•Positioning Precision: XY-axis 12.5 ㎛, Z-axis 1.25 ㎛

•Nozzle Diameter: Standard 0.4 mm (Interchangeable with 0.25, 0.6, 0.8 mm, etc.)

3. Build Size & Physical Specs

•Max Build Size (W x D x H): 260 x 260 x 260 mm

•Printer Dimensions: Approx. 530 x 490 x 645 mm

•Printer Weight: Approx. 43 ~ 46 kg

•Power Consumption: Max 1200 W

4. Material Compatibility

•High-Performance Materials: PEEK, PEKK, ULTEM (PEI), PPSU, etc.

•Engineering & Standard Materials: PC, Nylon (PA), Carbon Fiber-Filled (PA-CF), ABS, ASA, PETG, TPU, PLA, etc.

•Open Filament System: Compatible with 1.75 mm filaments from 3rd-party brands

5. Key Features & Convenience

•Auto/Assisted Leveling: The "Enhanced" model supports sensor-based auto-leveling

•Safety & Monitoring: Filament run-out sensor, power failure recovery, and a built-in camera for remote monitoring

Dedicated Software: Includes INTAM-SUITE (Also compatible with Cura and Simplify3D)

1

Bambu Lab X1-Carbon

The Bambu Lab X1-Carbon is a high-performance FDM 3D printer that integrates ultra-fast printing with AI-driven technology. Below are its core specifications:

1. Major Specifications

•Printing Technology: FDM (Fused Deposition Modeling) based on the CoreXY architecture.

•Frame and Housing: Features a fully enclosed body with an aluminum frame and glass panels (door and side panels).

•AI Intelligent Features: Equipped with a 7 ㎛ resolution Micro Lidar and an AI camera for first-layer inspection and real-time "spaghetti" failure detection.

•User Interface: Includes a 5-inch high-resolution (1280 x 720) color touchscreen.

2. Printing Performance & Precision

•Max Print Speed: Supports ultra-high-speed printing up to 500 mm/s.

•Max Acceleration: Reaches up to 20,000 mm/s2, maintaining precision even during rapid direction changes.

•Max Nozzle Temperature: Capable of heating up to 300 °C

•Layer Thickness: Adjustable between 0.1 mm and 0.3 mm.

3. Build Size & Physical Specs

•Max Build Volume (W x D x H): 256 x 256 x 256 mm.

•External Dimensions: 389 x 389 x 457 mm

•Net Weight: 14.13 kg

4. Material Compatibility & AMS

•Supported Materials: Optimized for engineering plastics such as Carbon Fiber (CF) and Glass Fiber (GF) reinforced polymers, in addition to standard materials like PLA, PETG, TPU, ABS, and ASA.

•AMS (Automatic Material System): Automatically recognizes and switches between up to 4 filaments (expandable with a hub), supporting multi-color and multi-material prints.
